Pallet Rack in Atlanta, GA

The Fulton Industrial Boulevard district along I-20 and I-285 includes older buildings with 18–28 ft clear height. Newer distribution space along I-75 South through Henry County can offer 32–40 ft clear. Neither range is a promise about your building; we need the available height and overhead restrictions before counting storage levels.

In Gwinnett and Cobb, smaller flex and light-industrial spaces often combine receiving, storage and picking in a limited footprint. For a parts wholesaler in Marietta or Lawrenceville, keeping each item accessible may be worth more than putting another row into the plan. We compare usable positions with the movement required to retrieve them.

Forklift reach sets a practical limit on the highest usable beam. Aisle widths must suit the truck, its turning requirements and the load being handled. The CAD drawing should show those working aisles, not simply rows packed into an empty outline.

A beam capacity figure applies to a specified span and loading arrangement. Give us the heaviest pallet, not just an average, and identify overhang or uneven loads. Upright capacity also depends on the finished configuration, including beam elevations. We review the system as a whole rather than treating a beam label as approval for every possible arrangement.

If you are adding bays or reconfiguring existing rack, send manufacturer information, component measurements and photographs. Similar-looking connectors are not enough to establish compatibility. Changing elevations may require another configuration review; older material with uncertain identification should not be assumed suitable for the new layout.

Your itemized scope separates new components, drawings and installation. Shipping availability and crew scheduling are checked against that scope. Atlanta's hot, humid summers make staging and crew planning important in non-air-conditioned warehouses, particularly when receiving and order picking must continue beside the work area.

The row drawing gives your warehouse team a clear view of pallet positions, beam elevations and working aisles. We compare the highest loaded pallet with the building's usable clear height and the forklift's reach. Receiving, reserve storage and daily picking should each have an identified place in the arrangement. Before installation begins, we agree which rows can be released and where incoming components will wait.

What's Included:

• Free warehouse consultation
• CAD layout drawings
• Itemized project quote
• Rack type recommendations
• Installation timeline

How do I choose rack dimensions?

When can delivery and installation be scheduled?

What determines the cost of pallet rack?

How do you confirm pallet rack capacity?

Which rack system fits our inventory?
